CardioTouch Screen and User Controls
Volume Keys6Incline Keys1
STOP Key7Incline Display2
Fan Key8CardioTouch Screen3
Channel Key9Resistance Display4
Resistance Keys5
Incline and Resistance are shown in the LED displays.Displays
User controls for Incline, Resistance, Volume, STOP, Fan and Channel.Keys
Tap the icons to make selections.CardioTouch
screen
Muscle Map and Incline Meter
An anatomical representation of the human body with primary muscle groups lit
by multi-color LED’s. The color of the LED displays which muscle groups are tar-
geted and the relative intensity of the exercise.
Muscle Map
Page 23 of 202
Cybex 772A, 772AT Arc Trainer Part Number
