OEM Diags (Diagnostics)
1. Tap the OEM Diags icon to display the OEM Diagnostics menu.
OEM Diagnostics menu:
Displays software versions and component information.
Base S/N, Console S/N, MCC Code Revision, GFX Code Revision, EPEM or
LED Code Revision, Drive Revision, Install date, Date/Time, HR Device
name/type, Errors (# of errors in the log), Brake Type
Build Report
Displays number of errors, up to 20. If no errors are stored [ 0 ] [Err ] [Log] will
be displayed. See Error Codes.
Error Log
Display battery and charger system info.
SPM, Charge State, Charge Current, Battery Voltage, Battery Level, Power
Source, LCB uP Temp.
Power System
Test CardioTouch screen. Touch anywhere on screen to display cross hairsTouch Test
Touch four corners to calibrate CardioTouch screen.Touch Cal
2.
Tap the Toolbox icon to return to the Toolbox screen.
Exit Diagnostics
Exit Diagnostics by tapping the Toolbox icon, then tap the Home icon . The screen will
refresh.
Diagnostics when CardioTouch screen is not functioning
The incline motor and resistance can be tested if the CardioTouch Screen is not functioning.
1.
Press and hold the Fan key for at least three seconds until the console beeps twice.
2.
Release the Fan key and press the Volume Down key within two seconds.
The Incline and Resistance LED’s will blink indicating Diagnostics Mode.
Press any one of the Incline or Resistance keys within the first ten seconds, otherwise Diagnostic
Mode will exit.
3.
The Incline Up , Incline Down , Resistance Up and Resistance Down keys
are now active.
4.
Press the Stop key to exit to Dormant Mode.
Page 37 of 202
Cybex 772A, 772AT Arc Trainer Part Number
