3. Insert USB stick into the internal USB port.
Do NOT insert USB stick into optional E3 View Monitor.
Qty.DescriptionItem
1
Internal USB port, MCC
board
1
4. Plug the power cord into the power outlet.
Console damage may occur.Do NOT turn the power off, press any keys,
or remove the USB stick during this procedure.
The software will load into the console. This procedure will take approximately 3 minutes. During
this time there will be beeping noises from the console. When the upload is complete, the display
will show [re][bot].
5. Unplug power cord from the power outlet.
6. Remove USB stick from internal USB port.
Install software through external USB port
1. Insert USB stick into the external USB port.
Qty.DescriptionItem
1External USB port1
Page 90 of 202
Cybex 772A, 772AT Arc Trainer Part Number
