Remove heart rate cable
Unplug heart rate cable from socket in frame.
Qty.DescriptionItem
1Socket in frame1
1Heart rate cable2
Remove front arm handle linkage
1. Remove screw, flat washer, cap, and spacer securing arm handle linkage using a 3/16” Allen wrench.
Qty.DescriptionItem
1Screw1
1Flat washer2
1Cap3
1Spacer4
1Arm handle linkage5
1Handle6
2. Remove arm handle linkage from handle.
Page 99 of 202
Cybex 772A, 772AT Arc Trainer Part Number
