Cygnus 1 User Manual

Introduction
10
CYGNUS 1 ROV SPECIFICATION – SHALLOW-WATER GAUGE
Materials
Sound Velocity from 1000 m/s to 9995 m/s
[0.0400 in/uS to 03998 in/uS]
Range
Typical Measurable Range in Steel :
with 2¼ MHz Probe : 3mm to 250mm [0.120 in. to 10.0 in.]
with 3½ MHz Probe : 2mm to 150mm [0.080 in. to 6.0 in.]
Resolution
0.1 mm [0.005 in.] or
0.05 mm [0.002in.]
Accuracy
± 0.1 mm [± 0.005 in.] or
± 0.05 mm [± 0.002 in.]
Probes
Single-Crystal, Soft-face Compression Probes :
¾ 2¼ MHz : 13mm [0.5 in.]
¾ 2¼ MHz : 19mm [0.75 in.]
¾ 3½ MHz : 13mm [0.5 in.]
Operating
Temperature
Recommended :
-10°C to +50°C [14°F to 122°F]
Power Supply
Power Supply Requirement :
7.5 – 30 Vdc @ 100mA typical, 150mA maximum
Data-link
RS-422 Communication, differential pair, single direction
Display
Software
Computer Requirement :
Windows
®
-compatible PC or Laptop (486 minimum) with 45
MB free hard disk space
One free Serial COM-port, or a USB connection
Size
Gauge-Body dimensions, excluding cabling :
Length 237 mm x Diameter 70 mm [9.3 in. x 2.8 in.]
Probe-Cable length : 5 metre [16 ft. 5 in.]
Weight in Air
With Remote Probe – 1.25 Kg [44 ounce]
Water Depth
Fully Waterproof :
Pressure tested to a depth of 1000 m [3281 ft.]
