Measuring with the Gauge
44
TABLE OF SOUND VELOCITIES
Velocity of Sound
Mate
rial
m/s
in/us
Conversion
Factor
Aluminium
6320
0.2488
1.068
Epoxy
2500
0.0986
0.422
Copper
4700
0.1850
0.794
Grey Cast Iron
4600
0.1812
0.777
Magnesium
5770
0.2272
0.975
Nickel
5630
0.2218
0.951
Acrylic
2730
0.1076
0.461
Nylon (Polyamide)
2620
0.1032
0.443
Porcelain
5600
0.2206
0.946
Glass
Quartz
Soda-lime
Borosilicate
5570
6000
5640
0.2194
0.2362
0.2222
0.941
1.014
0.953
Steel
Mild
Tool
Stainless 302
5920
5870
5660
0.2332
0.2312
0.2228
1.000
0.992
0.956
Tungsten
5460
0.2150
0.922
Monel
5400
0.2126
0.912
Inconel
5700
0.2244
0.963
Phosphor Bronze
3530
0.1390
0.596
Brass (70% Cu)
4700
0.1850
0.794
44
46
Table of Contents
Table of Contents
4
Introduction
6
Cygnus 1 ROV Ultrasonic Thickness Gauge
7
Cygnus Instruments
8
The Multiple-Echo Method
9
Cygnus 1 ROV Specification - Deep-Water Gauge
10
Cygnus 1 ROV Specification - Shallow-Water Gauge
11
Cygnus 1 ROV Specification - Mini-ROV Lightweight Gauge
12
Selection of Ultrasonic Probes
13
Serial Data Format
14
Installing the Underwater Gauge
16
Cygnus 1 ROV Kit Contents - Deep-Water & Shallow-Water Gauge
17
Cygnus 1 Rov Kit Contents Mini-Rov Lightweight Gauge
18
Gauge Assembly & Disassembly
19
Underwater Cable Connector
20
Probe/Knurled Ring Assembly
21
Data & Power Connections
22
Viewing Measurements on the Pc
24
Computer Connection Options
25
Installing the Cyglink Program
26
Installing the USB-To-Serial Adaptor Drivers
27
Connecting the System Together
28
Using the Cyglink Remote Display Program
32
Measuring with the Gauge
35
Controls
36
Calibrating the Gauge
36
Measurement
39
Probe Usage
40
Troubleshooting
41
General Points on Thickness Gauging
43
A Guide to Sound Velocities
44
Table of Sound Velocities
45
Working with Log-Files
46
About Log-Files
47
Viewing Log-Files
48
Creating a Report File
49
Printing Files Using Cyglink
51
File Format
52
Creating Template-Files Using Cyglink
53
About Template-Files
54
Creating a Single-Record File
55
Creating a Multi-Record File
56
Creating a Key-Point File
57
Creating a Grid-Point File
62
Remote-Logging
64
Using Remote-Logging
65
Quick Logging
66
Remote-Logging to Datalogger Files
69
Logging to a Single-Record File
70
Logging to a Multi-Record File
72
Logging to a Key-Point File
74
Logging to a Grid-Point File
76
Care and Servicing
81
Care of the Cygnus 1 ROV Gauge
82
Servicing
83
Recycling & Disposal
84
Rohs Directive
84
