Remote-Logging
75
LOGGING TO A GRID-POINT FILE
To start a Grid-Point logging session :
Ö Select Remote-Logging Open → Log-File → Grid-Point… option on the main
window menu-bar :
¾ The
Grid-Point Remote-Logging
window will open
Open a file for Remote-Logging :
Ö Either : click on the Open New button open a new Logfile
This allows you to open a new file, using a Template file [with a .gs0 file extension] :
a file previously created in CygLink from the
Create a New File
menu
See : Creating a Grid-Point File
, page 61
Ö Or : click on the Open button to open an existing Logfile
This allows you to reopen an existing Grid-Point file [with a .gs1 file extension] :
a file previously opened for a Remote-Logging session
The file contents are now read into the
Grid-Point
pane :
¾ For a new file : all of the Reading values will be listed as missed, meaning that the no
Readings have yet been attempted
¾ All of the Readings from the first Grid-Point Record in the Grid-Point file will appear in
the list in the
Grid-Point
pane : use the scrollbar on the right-hand side of the list to
view the current Readings
The presentation of the Grid-Point Records, and of the Readings which appear in the list,
depends on whether the file was designated to take Readings across Rows or down Columns,
and also whether there are single or multiple Readings required at each Grid-Point
There are thus three variations for the Grid-Point file display :
¾ Grid-Point file with multiple Readings at each measurement point
¾ Grid-Point file with a single Reading at each measurement point, specified for
measurement across Rows
¾ Grid-Point file with a single Reading at each measurement point, specified for
measurement up/down Columns
