Field Description
Source Port Mask
Defines the range of source Ports relevant to the ACL rules. (0=ignore, 1=check).
For example, to set 0 – 15, set mask of F.
Destination Port Mask
Defines the range of destination IP addresses, relevant to the ACL rules. (0=ignore,
1=check).
For example, to set 0 – 15, set mask of F.
2. Select Source Port Mask and/or Destination Port Mask. The Mask Generate button is active.
3. Enter a port ID in the box adjacent to the Mask Generate button.
Alternatively, click
.
The Generate Mask by range fields appear.
Enter a port ID range into the Generate Mask by range fields, and click
. The mask is generated.
4. Click
. The ACL profile is added, and the device is updated.
NOTE: A combination of one or several filtering masks can be selected simultaneously. The page
updates with the relevant field(s).
