D-Link DAP-1665 User Manual

78D-Link DAP-1665 User Manual
Section 5 - Connecting a Wireless Client
Connecting to a Wireless Client
WPS Button
WPS (Wi-Fi Protected Setup) is a simple and secure way to connect your wireless devices with the DAP-1665 when using
Repeater or Wireless Client mode. Most wireless devices such as wireless routers, media players, printers, and cameras will have
a WPS button (or a software utility with WPS). Refer to the user manual for the wireless device you want to connect to make
sure you understand how to enable WPS. Once you know, follow the steps below:
Step 1 - Press the WPS button on the DAP-1665 for a minimum of one second.
The LED on the device will start to blink. (You can also use the WPS option
in the Wi-Fi Setup Wizard as described in the Conguration section.)
Step 2 - Within 120 seconds, press the WPS button on your wireless device.
Step 3 - Allow up to one minute to connect. When the LED stops blinking and
turns solid green, you will be connected and your wireless connection
will be secured with WPA2.
WPS Button

D-Link DAP-1665 Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.4835, 5.15 - 5.35, 5.47 - 5.85 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1200 Mbit/s
Internal	No
Certification	CE\\r FCC\\r TELEC\\r IC\\r Wi-Fi Certified\\r VCCI
Cable lock slot type	Kensington
Ethernet LAN (RJ-45) ports	1
Security algorithms	128-bit WEP, 64-bit WEP, WPA-PSK, WPA2-PSK, WPS
Antenna type	External
Antenna features	Detachable antenna
Antennas quantity	2
Antenna gain level (max)	2 dBi
Input current	1 A
AC input voltage	12 V
Power consumption (typical)	5.18 W
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Package depth	274 mm
Package width	208 mm
Package height	68 mm
Package weight	669.4 g
Pallet width	1100 mm
Pallet length	1200 mm
Pallet height (air)	1989 mm
Pallet gross weight (air)	333920 g
Quantity per pallet (air)	420 pc(s)
Shipping (inner) case width	360 mm
Shipping (inner) case height	309 mm
Shipping (inner) case length	441 mm
Shipping (inner) case weight	7510 g
Shipping (inner) case net weight	3480 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	10 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	108 mm
Width	147 mm
Height	27.8 mm
Weight	222 g
