D-Link DAP-2695 User Guide

55D-Link DAP-2695 User Manual
Web User Interface
MAC Bypass
The DAP-2695 features a wireless MAC Bypass. Once a user is nished with these settings, click the Save button to let the changes take eect.
Wireless Band:
SSID Index:
MAC Address:
MAC Address List:
Upload File:
Load MAC File to Local
Hard Driver:
Select the wireless band for MAC Bypass.
Select the SSID for MAC Bypass.
Enter each MAC address that you wish to
include in your bypass list, and click Add.
When a MAC address is entered, it appears
in this list. Highlight a MAC address and
click the Delete icon to remove it from this
list.
To upload a MAC bypass list le, click
Browse and navigate to the MAC bypass list
le saved on the computer, and then click
Upload.
To download the MAC bypass list le, click
Download and to save the MAC bypass list.

D-Link DAP-2695 Specifications

Operating Environment

operating temperature	0˚C to 40˚C
storage temperature	-20˚C to 65˚C
operating humidity	10%~90% (non-condensing)
storage humidity	5%~95% (non-condensing)

Power

operating voltage	48V DC +/- 10% for PoE
voltage and current for PoE	48V/0.5A

Wireless Specifications

wireless frequency range	2.4 to 2.4835 GHz and 5.15 to 5.85 GHz
antenna type at 2.4GHz	3x Detachable 4 dBi Omni antennas
antenna type at 5GHz	3x Detachable 6 dBi Omni antennas

Weight and Dimensions

length	198.8 mm
width	190 mm
height	36.5 mm
