D-Link DAP-2695 User Guide

64D-Link DAP-2695 User Manual
Web User Interface
The trac manager feature allows users to create trac management rules that specify how to deal with listed client trac and specify
downlink/ uplink speed for new trac manager rules. Click the Save button to let your changes take eect.
Trac Manager:
Unlisted Client Trac:
Downlink Bandwidth:
Uplink Bandwidth:
Name:
Client IP (optional):
Client MAC (optional):
Downlink Speed:
Uplink Speed:
Use the drop-down menu to Enable the
trac manager feature.
Select Deny or Forward to determine how
to deal with unlisted client trac.
The downlink bandwidth in Mbits per
second. This value is entered in the Uplink/
Downlink Setting window.
The uplink bandwidth in Mbits per second.
This value is entered in the Uplink/Downlink
Setting window.
Enter the name of the trac manager rule.
Enter the client IP address of the trac
manager rule.
Enter the client MAC address of the trac
manager rule.
Enter the downlink speed in Mbits per
second.
Enter the uplink speed in Mbits per second.
Trac Manager

D-Link DAP-2695 Specifications

Operating Environment

operating temperature	0˚C to 40˚C
storage temperature	-20˚C to 65˚C
operating humidity	10%~90% (non-condensing)
storage humidity	5%~95% (non-condensing)

Power

operating voltage	48V DC +/- 10% for PoE
voltage and current for PoE	48V/0.5A

Wireless Specifications

wireless frequency range	2.4 to 2.4835 GHz and 5.15 to 5.85 GHz
antenna type at 2.4GHz	3x Detachable 4 dBi Omni antennas
antenna type at 5GHz	3x Detachable 6 dBi Omni antennas

Weight and Dimensions

length	198.8 mm
width	190 mm
height	36.5 mm
