D-Link DCS-1130 - Hardware Overview

5D-Link DCS-1130 User Manual
Section 1 - Product Overview
Hardware Overview
Front
Reset Button
Resetsthecameratofactorydefaults
when pressed for 10 seconds.
WPS Button
Allows you to connect to a WPS
router.
Focus ring
Turning the ring will allow you to
focus the camera.
Camera microphone
Picks up sound from the surrounding
area.
Camera lens
Recordsvideofromthesurrounding
area.
Status LED
Lights up and changes color to
indicatethecamera’sstatus.
