D-Link DCS-5300 User Manual

25D-Link DCS-5300 User Manual
Determine Your Router’s IP Address (WAN)
Note: Because a dynamic WAN IP can change from time to time depending on your ISP, you may want to obtain a
Static IP address from your ISP. A Static IP address is a fixed IP address that will not change over time and will be
more convenient for you to use to access your camera from a remote location.
• Open Virtual Server Ports to Enable Remote Image Viewing
The rewall security features built into the DI-614+ router prevent users from accessing the video from the DCS-5300
over the Internet. The router connects to the Internet over a series of numbered ports. The ports normally used by the
DCS-5300 are blocked from access over the Internet. Therefore, these ports need to be made accessible over the
Internet. This is accomplished using the Virtual Server function on the DI-614+ router. The Virtual Server ports used
by the camera must be opened through the router for remote access to your camera. Virtual Server is accessed by
clicking on the Advanced tab of the router screen.
Your WAN IP Address will be listed here.

D-Link DCS-5300 Specifications

General

Digital zoom	4 x
Maximum frame rate	30 fps
Camera shutter speed	1/60 - 1/15000 s
Minimum illumination	1 lx
Maximum video resolution	320 x 240 pixels
Pan range	270 °
Sensor type	CCD
Product color	Silver
Tilt angle range	-90 - 90 °
Built-in microphone	Yes
Optical sensor size	1/4 \
Focus	2.0
I/O ports	A/V MIC
Power supply type	12VDC 1.5A
Cabling technology	10BaseT, 100BaseT
Supported network protocols	TCP/IP, HTTP, SMTP, FTP, Telnet, NTP, DNS, DHCP
Compatible operating systems	Microsoft Windows XP, 2000, Me, 98SE
Dimensions (W x D x H) (imperial)	4.1 x 4 x 4.4 \
Minimum system requirements	Internet Explorer 5.x +
