D-Link DCS-5300 User Manual

13D-Link DCS-5300 User Manual
The following options are available on the Installation Wizard screen by clicking on the corresponding tab:
Click to search for any available cameras to connect to the network.
Click to manually add a camera to the network. A window will appear, prompting
you to enter the camera’s IP address or domain name. A second window will
appear, prompting you to enter the port number.
Click to remove the selected camera(s) from the network.
Click to uncheck all selected cameras.
Click to link all selected devices to the network.
On the initial Setup Screen you can congure System and Date/Time settings for
each camera. Click Next to congure Network settings for the camera.
Installation Wizard Screen
Search:
Add:
Remove:
Uncheck All:
Links to Selected
Devices:
Enter a Camera Name and create a Root password for the camera.
Enter the Date and Time for each camera. These settings can also be congured
on the Tools > System screen (page 53) when conguring the camera via a
Web browser.
System Settings:
Date/Time
Settings:

D-Link DCS-5300 Specifications

General

Digital zoom	4 x
Maximum frame rate	30 fps
Camera shutter speed	1/60 - 1/15000 s
Minimum illumination	1 lx
Maximum video resolution	320 x 240 pixels
Pan range	270 °
Sensor type	CCD
Product color	Silver
Tilt angle range	-90 - 90 °
Built-in microphone	Yes
Optical sensor size	1/4 \
Focus	2.0
I/O ports	A/V MIC
Power supply type	12VDC 1.5A
Cabling technology	10BaseT, 100BaseT
Supported network protocols	TCP/IP, HTTP, SMTP, FTP, Telnet, NTP, DNS, DHCP
Compatible operating systems	Microsoft Windows XP, 2000, Me, 98SE
Dimensions (W x D x H) (imperial)	4.1 x 4 x 4.4 \
Minimum system requirements	Internet Explorer 5.x +
