D-Link DCS-5300 User Manual

39D-Link DCS-5300 User Manual
Click the Audio/Video button from the Conguration screen to access video settings that affect how the video image
appears.
Configuration > Advanced > Audio/Video
Click Audio/Video
Check boxes to mute audio and/or improve audio quality in a low bandwidth environment.
Select either an internal or external microphone as the audio source. If you choose to use an external microphone,
connect it to the microphone connection at the rear of the DCS-5300.
Select the option for color or monochrome video display.
Three options exist for the sizes of the video display. You can select between 176x120/176x144, 352x240/352x288,
or 704x480/401x576. The rst value represents the PAL format of video and the second value represents the NTSC
format. In 704x480/401x576 mode, the frame rate will be reduced to 10fps and increased to 30fps automatically when
it is switched back to a lower image size.
Limits the maximum refresh frame rate. The frame rate is used with the Video quality control setting (below) to optimize
bandwidth utilization and video quality.
Audio Settings:
Audio Source:
Color:
Size:
Maximum frame
rate:

D-Link DCS-5300 Specifications

General

Digital zoom	4 x
Maximum frame rate	30 fps
Camera shutter speed	1/60 - 1/15000 s
Minimum illumination	1 lx
Maximum video resolution	320 x 240 pixels
Pan range	270 °
Sensor type	CCD
Product color	Silver
Tilt angle range	-90 - 90 °
Built-in microphone	Yes
Optical sensor size	1/4 \
Focus	2.0
I/O ports	A/V MIC
Power supply type	12VDC 1.5A
Cabling technology	10BaseT, 100BaseT
Supported network protocols	TCP/IP, HTTP, SMTP, FTP, Telnet, NTP, DNS, DHCP
Compatible operating systems	Microsoft Windows XP, 2000, Me, 98SE
Dimensions (W x D x H) (imperial)	4.1 x 4 x 4.4 \
Minimum system requirements	Internet Explorer 5.x +
