D-Link DCS-5300 User Manual

29D-Link DCS-5300 User Manual
The image from the DCS-5300 should be visible from the Home Page on
your computer monitor. To the right of the image are controls that allow
you to pan and tilt the camera. Pan and tilt can also be controlled within the
image. Clicking on any part of the image will cause the camera to reposition
itself so that the point will be the center of the image.
Home Page Screen
Return to home position.
Tilt/navigate camera using arrows
Select a preset position to move the camera to.
Select the speed at which the camera will pan or tilt.
Pans the camera one full cycle.
Stops movement of the camera during pan.
Enables the Auto Patrol feature.
Pull down menu:
Pan/Tilt Speed:
Auto Pan:
Stop:
Auto Patrol:
Click the Zoom button below the image to display the digital
zoom control panel. Using the bar, you can select to view the
image up to 400% of the original size.

D-Link DCS-5300 Specifications

General

Digital zoom	4 x
Maximum frame rate	30 fps
Camera shutter speed	1/60 - 1/15000 s
Minimum illumination	1 lx
Maximum video resolution	320 x 240 pixels
Pan range	270 °
Sensor type	CCD
Product color	Silver
Tilt angle range	-90 - 90 °
Built-in microphone	Yes
Optical sensor size	1/4 \
Focus	2.0
I/O ports	A/V MIC
Power supply type	12VDC 1.5A
Cabling technology	10BaseT, 100BaseT
Supported network protocols	TCP/IP, HTTP, SMTP, FTP, Telnet, NTP, DNS, DHCP
Compatible operating systems	Microsoft Windows XP, 2000, Me, 98SE
Dimensions (W x D x H) (imperial)	4.1 x 4 x 4.4 \
Minimum system requirements	Internet Explorer 5.x +
