D-Link DCS-5300 User Manual

24D-Link DCS-5300 User Manual
The following steps generally apply to any router that you have on your network. The D-Link DI-614+ is used as an
example to clarify the conguration process. Congure the initial settings of the DI-614+ by following the steps outlined
in the DI-614+ Quick Installation Guide.
• Access Your Router on Your Web Browser
If you have cable or DSL service, you will most likely have a dynamically assigned WAN IP Address. ‘Dynamic’ means
that your router’s WAN IP address can change from time to time depending on your ISP. A dynamic WAN IP Address
identies your router on the public network and allows it to access the Internet. To nd out what your router’s WAN IP
Address is, go to the Status screen on your router and locate the WAN information for your router. As shown on the
next page the WAN IP Address will be listed. This will be the address that you will need to type in your web browser
to view your camera over the Internet. Be sure to uncheck the Reset IP address at next boot button at the top of the
screen after modifying the IP address. Failure to do so will reset the IP address when you restart your computer.
These are the port settings for your camera. If
necessary, these ports can be changed if they are
already in use by other devices (e.g. in a multiple
camera environment).
Router Set-Up and Installation

D-Link DCS-5300 Specifications

General

Digital zoom	4 x
Maximum frame rate	30 fps
Camera shutter speed	1/60 - 1/15000 s
Minimum illumination	1 lx
Maximum video resolution	320 x 240 pixels
Pan range	270 °
Sensor type	CCD
Product color	Silver
Tilt angle range	-90 - 90 °
Built-in microphone	Yes
Optical sensor size	1/4 \
Focus	2.0
I/O ports	A/V MIC
Power supply type	12VDC 1.5A
Cabling technology	10BaseT, 100BaseT
Supported network protocols	TCP/IP, HTTP, SMTP, FTP, Telnet, NTP, DNS, DHCP
Compatible operating systems	Microsoft Windows XP, 2000, Me, 98SE
Dimensions (W x D x H) (imperial)	4.1 x 4 x 4.4 \
Minimum system requirements	Internet Explorer 5.x +
