Dual-Speed Stackable Hubs User’s Guide
Understanding Indicators18
Port State Indicators
There is one port state indicator for each of the twisted-pair ports on the hub.
Each port LED status indicator reports the port link and activity status,
and shows whether or not the port has been partitioned.
The following describes each indicator and the meaning of each condition:
♦ Link (green)
The indicator of a port lights green when the port is connected to a pow-
ered Ethernet or Fast Ethernet station. If the station to which the hub is
connected is powered off, or if there is a problem with the link, the LED
will remain off.
♦ Receive (blinking green)
When information is received on a port, its indicator will blink off briefly.
Upon reception, the data will be transmitted to all other connected ports.
♦ Auto-partition (blinking amber)
The indicator of a port blinks amber when the port is automatically parti-
tioned due to an abnormal network condition.
The hub will temporarily partition a port when too many line errors or too
many collisions are detected on the port. While the segment is automati-
cally partitioned, the port will be isolated from the rest of the network
segment. When the problem is corrected or a valid data packet is re-
ceived through the port, the port is automatically reconnected.
♦ Disabled (steady amber)
The indicator of a port is orange when the port has been manually dis-
abled. No packet transmission or reception can occur on the port.
