DGS-3100 Series Gigabit Stackable Managed Switch Hardware Installation Guide
5
This table describes the LED indicators for the DGS-3100-24 and DGS-3100-48:
Location LED Indicative Color Status Description
Solid Light Power On
Power
Green
Light off Power Off
Solid Light Console login CLI success
Console
Green
Light off Console logout CLI or time out
Solid Light RPS connected and RPS power on
RPS
Green
Light off RPS not connected or RPS power off
Flashing When any fans fail
Fan Err
Red
Light off When all fans work normally
Solid Light
When device is configured or selected to
be a stacking master
Master
Green
Light off When device is stacking slave
Number 1-6 Display the Stacking Unit ID
Flashing
Character ‘L’
Locates the master unit when the locator
function is enabled from user interface
Stacking ID
Green
Light off
Indicates the device is in stand alone
mode
Solid Light
A valid link is established on the stacking
HX port
Flashing
Data transmission or reception is
occurring on the stacking HX port
Per Device
SIO1/ SIO2
Green
Light off
No link is established on the stacking HX
port
Solid Light Link on 1000Mbps
Green
Flashing Activity
Solid Light Link 10Mbps or 100Mbps
Orange
Flashing Activity
LED Per
10/100/1000 Mbps
copper Port
Link/Act/Speed
Off Light off No link
Solid Light Link on 1000Mbps
Green
Flashing Activity
Solid Light Link 100Mbps
Orange
Flashing Activity
LED Per SFP Port Link/Act
Off Light off No link
Solid Light Link
Flashing Activity
LED Per Stacking
Port
Link/Act
Green
Light off No link
This table describes the LED indicators for the DGS-3100-24P and DGS-3100-48P:
Location LED Indicative Color Status Description
Solid Light Power On
Per Device
Power
Green
Light off Power Off
