Page #101 background image
99
5
prefix_type
Allows the prefix type to be selected as either 6to4
or Global/Local/ISATAP.
ipv6 prefix
type.
6
sla_id
The SLA ID (Site-Level Aggregation Identifier) in
the 6to4 address prefix is set for the interface ID on
which the advertisements are sent.
Unsigned
integer.
7
prefix_address
It specifies the IPv6 network address.
String.
8
prefix_length
The prefix length variable is a decimal value that
indicates the number of contiguous, higher order
bits of the address that make up the network
portion of the address.
Unsigned
integer.
9
prefix_life_time
The length of time over which the requesting router
is allowed to use the prefix.
Unsigned
integer.
7.21 net radvd pool delete <row_id>
S.No
Command Name
Description
Type and Description
1
<row_id>
radvd pool configuration mode.
Unsigned integer.
7.22 net routing dynamic configure
S.No
Command Name
Description
Type and
Description
1
save
Saves dynamic route changes.
2
exit
Saves dynamic routes changes
and exits current mode.
3
cancel
Rolls back RIP configuration
changes.
4
direction
RIP direction none, In only, out
only, both.
RIP direction
5
version
Rip version
RIP version
6
authentication_enable
Enables/disables authentication
for RIP-2B/2M.
Boolean choice.
7
first_key
First MD5 key.
8
first_key id_number
First MD5 key Id.
Unsigned integer.
9
first_key authentication_id
First MD5 Authentication key.
String.
10
first_key valid_from
First MD5 key not valid before
entered date.
11
first_key valid_from
month
Month in which MD5
authentication key validity starts.
Month in the format
MM(01-12)
