Page #48 background imageLoading...
Page #48 background image
46
2.19 wlan network delete <networkId>
S.No
Command Name
Description
Type and Description
1
<networkId>
Delete a network Profile
WLAN Network ID
2.20 wlan ap_profile ssid configure <profileid> <radio>
S.No
Command Name
Description
Type and
Description
1
<profileid> <radio>
Ssid for AP Profile.
AP Profile ID
wireless radio
interface
2
save
Save AP profile ssid settings.
3
exit
Save AP profile ssid settings and exit
current mode.
4
cancel
Roll back AP profile ssid settings changes.
5
vap
Configure the SSID for the network.
WLAN VAP ID
6
enable
Enable/Disable the VAP operational
mode.
Boolean choice
7
networkid
Configure the SSID for the network.
WLAN Network ID
2.21 wlan ap_profile apply <profileid>
S.No
Command Name
Description
Type and Description
1
<profileid>
Apply a AP Profile.
AP Profile ID
2.22 wlan captivePortal ssid configure <ssid>
S.No
Command Name
Description
Type and Description
1
<ssid>
Configure a SSID to associate to
captive Portal.
String
2
save
Save captive portal SSID
configuration changes.
3
exit
Save captive portal SSID changes
and exit current mode.
4
cancel
Roll back configuration changes.
5
showCP-profiles
Available captive portal profiles.
6
accessType
Access Type for the SSID to be
configure.
Captive Portal Type for
SSID
7
permanent-user
Access Type is Permanent User.
8
permanent-user
auth-mode
Authentication-server for user.
Authentication Type for
Captive Portal user
