D-Link DWC-2000 Cli Reference Guide

73
1
<interface>
Start the packet
capture.
Enter “util system_check capturePackets
avail_interfaces” command to get the available
interfaces for packet capture.
5.5 util system_check capturePackets download <fileName> <ipAddr>
S.No
Command Name
Description
Type and Description
1
<fileName> <ipAddr>
Download the packet
capture to the host
machine.
String
IP address AAA.BBB.CCC.DDD
where each part is in the range 0-
255
5.6 util schedule-reboot <enable_reboot>
S.No
Command Name
Description
Type and Description
1
<enable_reboot>
Reboot the system.
Boolean choice.
5.7 util usb_test <ipAddr> <fileName>
S.No
Command Name
Description
Type and Description
1
<ipAddr> <fileName>
To test the USB.
String.
5.8 util backup_configuration <fileName> <ipAddr>
S.No
Command Name
Description
Type and Description
1
<fileName> <ipAddr>
Download the backup
configuration file to the
host machine.
String
IP address AAA.BBB.CCC.DDD
where each part is in the range 0-
255
5.9 util restore_configuration <IpAddr> <FileName>
S.No
Command Name
Description
Type and Description
1
<IpAddr> <FileName>
For restoring the
configuration.
IP address AAA.BBB.CCC.DDD where
each part is in the range 0-255
String.
5.10 util firmware_upgrade <IpAddr> <FileName>
S.No
Command Name
Description
Type and Description
1
<IpAddr> <FileName>
For upgrading the
firmware.
IP address AAA.BBB.CCC.DDD where
each part is in the range 0-255
String.
6.0 Configuration commands under branch QOS

D-Link DWC-2000 Specifications

General

Security algorithms	802.1x RADIUS, WPA, WPA2
Data transfer rate	1 Gbit/s
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power consumption (typical)	26.95 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Compatible products	DWL-8610AP, DWL-8600AP, DWL-6600AP, DWL-3600AP, DWL-2600AP
Certification	FCC Class A, CE Class A, C-Tick, IC, cUL, LVD
Package depth	504 mm
Package width	444 mm
Package height	110 mm
Package weight	5846 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1095 mm
Pallet height (sea)	2055 mm
Pallet gross weight (air)	250560 g
Quantity per pallet (air)	36 pc(s)
Shipping (inner) case width	396 mm
Shipping (inner) case height	480 mm
Shipping (inner) case length	526 mm
Shipping (inner) case weight	18755 g
Shipping (inner) case net weight	17538 g
Number of cartons per pallet (air)	12 pc(s)
Quantity per shipping (inner) case	3 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Weight	3720 g
Dimensions (WxDxH)	440 x 310 x 44 mm
