D-Link DWC-2000 Cli Reference Guide

43
Description
1
<profileid> <radio>
wlan ap_profile QoS configuration mode
AP Profile ID
wireless radio
interface
2
save
Save AP profile QoS configuration.
3
exit
Save and exit current mode.
4
cancel
Roll back AP Profile QoS settings
changes.
5
enable_wmm_mode
Enable/Disable WMM mode.
Boolean choice
6
edca
Select between AP EDCA parameters
or Station EDCA parameters to
Configure.
AP EDCA
parameters or
Station EDCA
parameters
7
edca_queue
Select which EDCA queue to
configure(background, best-effort,
video, voice)
EDCA Parameters
8
aifs
Configure the Arbitration Inter-frame
Spacing time.
Unsigned integer
9
cwmin
Configure the upper limit of the range
from which the initial random backoff
wait time is determined.
Unsigned integer
10
cwmax
Configure the upper limit for the
doubling of the random backoff value.
Unsigned integer
11
max_burst
Configure the maximum burst duration.
Unsigned integer
2.18 wlan network configure <networkid>
S.No
Command Name
Description
Type and
Description
1
<networkid>
wlan network configuration
mode.
WLAN Network ID
2
save
Save Network settings.
3
exit
Save Network settings and exit
current mode.
4
cancel
Roll back Network settings
changes.
5
ssid
Configure the SSID for the
network.
String
6
hide_ssid
Enable/Disable hiding the SSID
for the network.
Boolean choice
7
ignore_broadcast
Enable/Disable deny broadcast

D-Link DWC-2000 Specifications

General

Security algorithms	802.1x RADIUS, WPA, WPA2
Data transfer rate	1 Gbit/s
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power consumption (typical)	26.95 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Compatible products	DWL-8610AP, DWL-8600AP, DWL-6600AP, DWL-3600AP, DWL-2600AP
Certification	FCC Class A, CE Class A, C-Tick, IC, cUL, LVD
Package depth	504 mm
Package width	444 mm
Package height	110 mm
Package weight	5846 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1095 mm
Pallet height (sea)	2055 mm
Pallet gross weight (air)	250560 g
Quantity per pallet (air)	36 pc(s)
Shipping (inner) case width	396 mm
Shipping (inner) case height	480 mm
Shipping (inner) case length	526 mm
Shipping (inner) case weight	18755 g
Shipping (inner) case net weight	17538 g
Number of cartons per pallet (air)	12 pc(s)
Quantity per shipping (inner) case	3 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Weight	3720 g
Dimensions (WxDxH)	440 x 310 x 44 mm
