36
8
debug
Enable/Disable debugging
on Managed AP.
9
debug passwd
Enter the admin password
for the AP (the default is
admin.
String
10
debug
passwd_confirm
Enter the admin password
again.
String
11
debug
enable_debug
Enable/Disable debugging
on Managed AP.
Boolean choice
12
reset
Reset a WS managed AP.
Boolean choice
2.2 wlan ap_management ap_database add <macaddr>
S.No
Command Name
Description
Type and Description
1
<macaddr>
wlan ap-management ap-
database configuration
mode.
MAC address AA:BB:CC:DD:EE:FF
where each part is in the range 00-
FF
2
save
Save ap-database
configuration changes.
3
cancel
Roll back ap-database
configuration changes.
4
exit
Save ap-database
configuration changes and
current mode.
5
mode
Configure the AP Managed
mode.
AP mode
6
location
Configure the AP location
description.
String
7
password
Configure the AP
Authentication Password.
String
8
profileid <1-16>
Set the AP Profile ID to use
for configuration.
AP Profile ID
9
ssid
Configure the stand-alone
AP expected SSID.
String
10
channel
Configure the stand-alone
AP expected channel.
Unsigned integer
11
wds_mode
Configure the stand-alone
AP expected WDS mode.
Stand-alone AP expected WDS
mode
12
security_mode
Configure the stand-alone
AP expected security
mode.
Stand Alone AP Security mode
13
wired-mode
Configure the stand-alone
