D-Link DWL-2100AP User Manual

10DWL-2100AP User Manual
Configuration
To configure the DWL-2100AP, use a computer which is connected to the DWL-2100AP with an Ethernet
cable. You may use the web-based configuration or the AP Manager software to configure your access
point. Please refer to page 52 to use the AP Manager software.
Web Configuration Utility
First, disable the Access the Internet using a proxy server function. To disable this function, go to Control
Panel > Internet Options > Connections > LAN Settings and uncheck the enable box.
Open your web browser program such as Internet Explorer. Type the IP address of the DWL-2100AP
in the address field (http://192.168.0.50) and press Enter. Make sure that the IP addresses of the
DWL-2100AP and your computer are in the same subnet.
After the connection is established, Enter your user name (admin) and your password (leave blank by
default). Click OK to continue.

D-Link DWL-2100AP Specifications

General

Frequency Band	2.4 GHz
Data Transfer Rate	54 Mbps
Security	WEP, WPA, WPA2
LAN Port	1 x 10/100Base-TX (RJ-45)
Device Type	Wireless Access Point
Form Factor	External
Data Link Protocol	IEEE 802.11b, IEEE 802.11g
Antenna Qty	1
Interface	1 x 10Base-T/100Base-TX - RJ-45
Power Supply	External power adapter
Wireless Standard	IEEE 802.11b/g
Antenna	Detachable
Compliant Standards	IEEE 802.11b, IEEE 802.11g
Encryption Algorithm	WEP, WPA, WPA2
Authentication Method	RADIUS
Features	MAC address filtering
Operating Modes	Access Point, Repeater
