D-Link DWL-2100AP User Manual

7DWL-2100AP User Manual
Front Panel
LAN
A blinking light indicates data is being
transmitted via the Ethernet port.
Power
A solid light indicates the
unit is properly powered.
WLAN
Blinking green indicates
wireless network activity.
Rear Panel
Ethernet Port
Connects the DWL-2100AP to a
router or switch using an Ethernet
cable.
Reset Button
Pressing this button restores
the Access Point to its original
factory default settings.
Power Receptor
Used to connect the supplied
power adapter.

D-Link DWL-2100AP Specifications

General

Frequency Band	2.4 GHz
Data Transfer Rate	54 Mbps
Security	WEP, WPA, WPA2
LAN Port	1 x 10/100Base-TX (RJ-45)
Device Type	Wireless Access Point
Form Factor	External
Data Link Protocol	IEEE 802.11b, IEEE 802.11g
Antenna Qty	1
Interface	1 x 10Base-T/100Base-TX - RJ-45
Power Supply	External power adapter
Wireless Standard	IEEE 802.11b/g
Antenna	Detachable
Compliant Standards	IEEE 802.11b, IEEE 802.11g
Encryption Algorithm	WEP, WPA, WPA2
Authentication Method	RADIUS
Features	MAC address filtering
Operating Modes	Access Point, Repeater
