D-Link DWL-2100AP User Manual

73DWL-2100AP User Manual
Configuration Files
The DWL-2100AP allows you to save the device settings to a configuration file. To save
a configuration file follow these steps:
 Select a device from the Device List on the main screen of the AP Manager.
Click the device configuration button.
 Click the Save button after you have all the settings as you want them.
A popup window will appear prompting you for a file name and location. Enter the
file name, choose a file destination, and click Save.
Device Configuration button.

D-Link DWL-2100AP Specifications

General

Frequency Band	2.4 GHz
Data Transfer Rate	54 Mbps
Security	WEP, WPA, WPA2
LAN Port	1 x 10/100Base-TX (RJ-45)
Device Type	Wireless Access Point
Form Factor	External
Data Link Protocol	IEEE 802.11b, IEEE 802.11g
Antenna Qty	1
Interface	1 x 10Base-T/100Base-TX - RJ-45
Power Supply	External power adapter
Wireless Standard	IEEE 802.11b/g
Antenna	Detachable
Compliant Standards	IEEE 802.11b, IEEE 802.11g
Encryption Algorithm	WEP, WPA, WPA2
Authentication Method	RADIUS
Features	MAC address filtering
Operating Modes	Access Point, Repeater
