53DWL-2100AP User Manual
Selecting Devices
The AP Manager allows you to configure multiple devices all at once. To select a single device, simply
click on the device you want to select. To select multiple devices, hold down the Ctrl key while clicking
on each additional device. To select an entire list, hold the Shift key, click on the first AP on the list and
then click on the last AP on the list.
IP Configuration
You can assign an IP address to an AP or assign IP addresses to multiple
AP’s by clicking on this button after selecting the device(s).
Select the AP that you want to assign an IP address to and click the IP button. Enter the IP address and
IP netmask for the selected device and click OK.
You can configure multiple AP’s with IP addresses all at once. Click on the IP button after you’ve selected
all of the AP’s you want to assign an IP address. Enter the IP address you want to assign the first unit
and the AP manager will automatically assign sequential IP addresses.
