D-Link DWL-2100AP User Manual

26DWL-2100AP User Manual
AP Repeater
IEEE 802.11g is selected here.
Select AP Repeater from the drop-down menu.
Select Enable to broadcast your SSID over the wireless network. Select Disable to
hide your SSID.
The channel used will be displayed. The channel will follow the root AP.
This feature is not available in Repeater mode.
Click on Scan and select the root AP you with to repeat. When you select the AP, the
MAC Address and the SSID fields will populate.
Select Open System or Shared Key. Refer to the next page.
Disabled by default. You can select Enable if the access point you are
connecting to is using Super G mode.
Wireless Band:
Mode:
SSID Broadcast:
Channel:
Auto Channel Scan:
Root AP MAC Address/
SSID:
Authentication:
Super G Mode:

D-Link DWL-2100AP Specifications

General

Frequency Band	2.4 GHz
Data Transfer Rate	54 Mbps
Security	WEP, WPA, WPA2
LAN Port	1 x 10/100Base-TX (RJ-45)
Device Type	Wireless Access Point
Form Factor	External
Data Link Protocol	IEEE 802.11b, IEEE 802.11g
Antenna Qty	1
Interface	1 x 10Base-T/100Base-TX - RJ-45
Power Supply	External power adapter
Wireless Standard	IEEE 802.11b/g
Antenna	Detachable
Compliant Standards	IEEE 802.11b, IEEE 802.11g
Encryption Algorithm	WEP, WPA, WPA2
Authentication Method	RADIUS
Features	MAC address filtering
Operating Modes	Access Point, Repeater
