D-Link DWL-2100AP User Manual

39DWL-2100AP User Manual
Static Pool Settings
DHCP Server
Control:
Assigned IP:
Assigned MAC
Address:
SubMask:
Gateway:
Dynamic Host Configuration Protocol assigns IP addresses to
wireless devices on the network. This protocol simplifies network
management and allows new wireless devices to receive IP
addresses automatically without the need to manually assign IP
addresses.
Select Enable to allow the DWL-2100AP to function as a DHCP
server.
Use the Static Pool Settings to assign the same IP address to a
device at every restart. The IP addresses assigned in the Static Pool
list must NOT be in the same IP range as the Dynamic Pool. After you
have assigned a static IP address to a device via its MAC address,
click Apply; the device will appear in the Assigned Static Pool at
the bottom of the screen. Edit or delete the device in this list.
Enter the MAC address of the device here.
Enter the subnet mask here.
Enter the IP address of the gateway on the network.

D-Link DWL-2100AP Specifications

General

Frequency Band	2.4 GHz
Data Transfer Rate	54 Mbps
Security	WEP, WPA, WPA2
LAN Port	1 x 10/100Base-TX (RJ-45)
Device Type	Wireless Access Point
Form Factor	External
Data Link Protocol	IEEE 802.11b, IEEE 802.11g
Antenna Qty	1
Interface	1 x 10Base-T/100Base-TX - RJ-45
Power Supply	External power adapter
Wireless Standard	IEEE 802.11b/g
Antenna	Detachable
Compliant Standards	IEEE 802.11b, IEEE 802.11g
Encryption Algorithm	WEP, WPA, WPA2
Authentication Method	RADIUS
Features	MAC address filtering
Operating Modes	Access Point, Repeater
