DWR-956 Wireless AC1200 4G LTE Router
with Gigabit Ethernet Ports and 1 FXS Port
User Manual
Configuring via Web-based Interface
Figure 152. The window for changing the settings of the router's port.
In the opened window, specify the needed parameters:
Parameter Description
Speed
Select the Auto value to enable autonegotiation. When this value is
selected, the Autonegotiation Modes and Flow control sections
are displayed.
Select the 10M-Half, 10M-Full, 100M-Half, or 100M-Full value
to manually configure speed and duplex mode for the selected port.
• 10M-Half: Data transfer in just one direction at a time (data
can be either sent or received) at the maximum possible rate
of up to 10Mbps.
• 10M-Full: Data transfer in two directions simultaneously
(data can be sent and received at the same time) at the
maximum possible rate of up to 10Mbps.
• 100M-Half: Data transfer in just one direction at a time (data
can be either sent or received) at the maximum possible rate
of up to 100Mbps.
• 100M-Full: Data transfer in two directions simultaneously
(data can be sent and received at the same time) at the
maximum possible rate of up to 100Mbps.
Page 196 of 302
