DWR-956 Wireless AC1200 4G LTE Router
with Gigabit Ethernet Ports and 1 FXS Port
User Manual
Configuring via Web-based Interface
,
Select the needed operation mode and click the NEXT button.
Router
In order to connect your device to a private Ethernet line, on the Device mode page, from the
Connection method list, select the Ethernet value. Then from the Work mode list, select the
Router value. In this mode you can configure one of the router's LAN port as the WAN port,
configure a WAN connection, set your own settings for the wireless network in the 2.4GHz and
5GHz bands, configure LAN ports to connect an STB or VoIP phone, and set your own password
for access to the web-based interface of the device.
Figure 35. Selecting an operation mode. The Router mode.
In order to connect your device to the network of a 3G or LTE operator, on the Device mode
page, from the Connection method list, select the Mobile Internet value. In this mode you can
configure a 3G/LTE WAN connection, set your own settings for the wireless network in the
2.4GHz and 5GHz bands, and set your own password for access to the web-based interface of the
device.
Figure 36. Selecting an operation mode. The Mobile Internet mode.
Page 47 of 302
