DWR-956 Wireless AC1200 4G LTE Router
with Gigabit Ethernet Ports and 1 FXS Port
User Manual
Configuring via Web-based Interface
You can specify the following parameters:
Parameter Description
General Settings
Enable rule
Move the switch to the right to enable the rule.
Move the switch to the left to disable the rule.
Name
A name for the rule for easier identification. You can specify any
name.
Action
Select an action for the rule.
• Allow: Allows packet transmission in accordance with the
criteria specified by the rule.
• Deny: Denies packet transmission in accordance with the
criteria specified by the rule.
Protocol
A protocol for network packet transmission. Select a value from the
drop-down list.
IP version
An IP version to which the rule will be applied. Select the relevant
value from the drop-down list.
Direction
The direction of network packet transmission to which the rule will
be applied. Select the source of the packet direction from the
Source drop-down list.
• WAN: The rule will be applied to the packets transmitted
from the external network.
• LAN: The rule will be applied to the packets transmitted
from the local network.
• GRE: The rule will be applied to the packets transmitted
from the GRE tunnel (available if a GRE tunnel has been
created on the device).
• IPsec: The rule will be applied to the packets transmitted
from the IPsec tunnel (available if an IPsec tunnel has been
created on the device).
• PPTP Server: The rule will be applied to the packets
transmitted from the PPTP server (available if a PPTP server
has been created on the device).
• L2TP Server: The rule will be applied to the packets
transmitted from the L2TP server (available if an L2TP
server has been created on the device).
Page 247 of 302
