D-Link GO-RT-N300 User Manual

42D-Link GO-RT-N300 User Manual
Section 3 - Conguration
The Virtual Server page allows you to open a single port. If you would like to open a range of ports, refer to the next page.
Select an application from the drop-down menu or
type a name in the next field.
Enter a service name.
Select TCP or UDP from the Protocol drop-down menu.
Enter the WAN port number.
Enter the LAN Open port number.
Enter the IP address of the computer on your local
network that you want to allow the incoming service to.
Usual Service
Name:
User-defined
Service Name:
Protocol:
WAN Port:
LAN Open Port:
LAN IP Address:
Click the Apply Changes button to save any changes made. The virtual server will then be added to the Current Virtual Server
Forwarding Table below. To delete or disable a virtual server, click the Delete or Disable buttons in the Action field of the
virtual server in the table.
GO-RT-N300

D-Link GO-RT-N300 Specifications

Wireless Signal Rates

IEEE 802.11n 20MHz channel	150 Mbps (max)
IEEE 802.11n 40MHz channel	300 Mbps (max)
IEEE 802.11g rates	54 Mbps - 48 Mbps - 36 Mbps - 24 Mbps - 18 Mbps - 12 Mbps - 11 Mbps - 9 Mbps - 6 Mbps

Operating Environment

operating temperature	0 °C to 40 °C (32 °F to 104 °F)
storage temperature	-20 °C to 65 °C (-4 °F to 149 °F)
humidity	10% minimum to 95% maximum (non-condensing)

Dimensions

length	160 mm (6.3 inches)
width	120 mm (4.72 inches)
height	59 mm (2.32 inches)
