Section 3 - Conguration
WPS Setup
PIN of the
Router:
Enable WPS:
Disable PIN:
Keep Current
Configuration:
ACL Setup:
Displays the current PIN for the router’s WPS connection.
Wireless clients connecting to the router using the PIN
method should enter this PIN in order to connect.
Check the box to enable devices to connect to the router
using WPS.
Check the box to disable the PIN connection method. If this
option is disabled, clients can only use the PBC method to
connect.
Check this box to lock the current conguration. If this
option is disabled, wireless clients will not be able to
automatically adjust the router’s WPS settings when
connecting.
Click this button to be taken to the Access Control setup
tab, where you can congure lters to control which
wireless clients access your network, and which network
resources they can access. For more information on
conguring access control, please refer to “Access Control
List” on page <?>.
Click Apply Changes to save the current conguration.

D-Link GO-RT-N300 Specifications

Wireless Signal Rates

IEEE 802.11n 20MHz channel	150 Mbps (max)
IEEE 802.11n 40MHz channel	300 Mbps (max)
IEEE 802.11g rates	54 Mbps - 48 Mbps - 36 Mbps - 24 Mbps - 18 Mbps - 12 Mbps - 11 Mbps - 9 Mbps - 6 Mbps

Operating Environment

operating temperature	0 °C to 40 °C (32 °F to 104 °F)
storage temperature	-20 °C to 65 °C (-4 °F to 149 °F)
humidity	10% minimum to 95% maximum (non-condensing)

Dimensions

length	160 mm (6.3 inches)
width	120 mm (4.72 inches)
height	59 mm (2.32 inches)
