D-Link GO-RT-N300 User Manual

33D-Link GO-RT-N300 User Manual
Section 3 - Conguration
This page allows you to set up an Access Control List to restrict the types of data packets that can enter the network from the
Internet.
Access Control List
Advanced
Use the drop-down menu to select either WAN or IP
address.
This option will only be seen if you have selected IP address
above. Enter the IP address range for this rule.
Select the type of Internet service of which packets will be
allowed into the network:
Web - Allows web services from the specified IP address
into the network. You will also be required to enter a port
number for the IP address range.
Ping - Allows your network to receive ‘ping’ requests from
the specified IP address range.
The Current ACL Table will show a summary of current
access control rules.
Click Delete to remove a rule from the list.
WAN Setting:
IP Address:
Services Allowed:
Click the Add button to save and add these settings to the Current ACL table.

D-Link GO-RT-N300 Specifications

Wireless Signal Rates

IEEE 802.11n 20MHz channel	150 Mbps (max)
IEEE 802.11n 40MHz channel	300 Mbps (max)
IEEE 802.11g rates	54 Mbps - 48 Mbps - 36 Mbps - 24 Mbps - 18 Mbps - 12 Mbps - 11 Mbps - 9 Mbps - 6 Mbps

Operating Environment

operating temperature	0 °C to 40 °C (32 °F to 104 °F)
storage temperature	-20 °C to 65 °C (-4 °F to 149 °F)
humidity	10% minimum to 95% maximum (non-condensing)

Dimensions

length	160 mm (6.3 inches)
width	120 mm (4.72 inches)
height	59 mm (2.32 inches)
