D-Link GO-RT-N300 User Manual

4D-Link GO-RT-N300 User Manual
Section 1 - Product Overview
Pressing the Reset Button restores
the router to its original factory
default settings.
The Internet port is the
connection for the Ethernet
cable to the Cable or DSL
modem.
The On/Off button turns
the device on or off.
LAN Ports
Connect Ethernet devices such as
computers, switches, and hubs.
Receptor for the Power Adapter.
Hardware Overview
Connections

D-Link GO-RT-N300 Specifications

Wireless Signal Rates

IEEE 802.11n 20MHz channel	150 Mbps (max)
IEEE 802.11n 40MHz channel	300 Mbps (max)
IEEE 802.11g rates	54 Mbps - 48 Mbps - 36 Mbps - 24 Mbps - 18 Mbps - 12 Mbps - 11 Mbps - 9 Mbps - 6 Mbps

Operating Environment

operating temperature	0 °C to 40 °C (32 °F to 104 °F)
storage temperature	-20 °C to 65 °C (-4 °F to 149 °F)
humidity	10% minimum to 95% maximum (non-condensing)

Dimensions

length	160 mm (6.3 inches)
width	120 mm (4.72 inches)
height	59 mm (2.32 inches)
