D-Link GO-RT-N300 User Manual

38D-Link GO-RT-N300 User Manual
Section 3 - Conguration
Enter the total bandwidth.
Click to enable auto traffic shaping.
Select the data protocol which you want to set a QoS rule for.
Enter the source IP.
Enter the destination IP.
Enter the source port number if applicable. This box will be greyed out for certain protocols.
Enter the minimum upload speed.
Total Bandwidth
(0, Unlimited):
Auto Traffic
Shaping:
Protocol:
Source IP:
Dest IP:
Source Port:
Up Floor:
Traffic Control
This page allows you to configure traffic bandwidth and rules for network traffic.
QoS Rules
Click the Add button once to view the QoS Rules settings.
GO-RT-N300

D-Link GO-RT-N300 Specifications

Wireless Signal Rates

IEEE 802.11n 20MHz channel	150 Mbps (max)
IEEE 802.11n 40MHz channel	300 Mbps (max)
IEEE 802.11g rates	54 Mbps - 48 Mbps - 36 Mbps - 24 Mbps - 18 Mbps - 12 Mbps - 11 Mbps - 9 Mbps - 6 Mbps

Operating Environment

operating temperature	0 °C to 40 °C (32 °F to 104 °F)
storage temperature	-20 °C to 65 °C (-4 °F to 149 °F)
humidity	10% minimum to 95% maximum (non-condensing)

Dimensions

length	160 mm (6.3 inches)
width	120 mm (4.72 inches)
height	59 mm (2.32 inches)
