D-Link GO-RT-N300 User Manual

11D-Link GO-RT-N300 User Manual
Section 2 - Installation
The GO-RT-N300 will run a Setup Wizard when you first use it. Follow the simple steps below to run the Setup Wizard to guide
you quickly through the installation process.
Select your WAN network type, then enter your wireless SSID and key.
Click the Save and Connect button when you are finished.
Getting Started
Note: It is recommended to write down the SSID and security key, followed by the login password.
Open a web browser (such as Internet Explorer) and enter the IP
address of the router (http://192.168.0.1) in the address bar. The
setup wizard will start automatically
The network map at the top of the page shows your current network
connections. A green tick represents a successful connection
between two devices. The IP address of each device will also be
displayed. You can change the language of the configuration utility
by selecting your desired language from the drop-down menu in
the top right-hand corner of the screen.

D-Link GO-RT-N300 Specifications

Wireless Signal Rates

IEEE 802.11n 20MHz channel	150 Mbps (max)
IEEE 802.11n 40MHz channel	300 Mbps (max)
IEEE 802.11g rates	54 Mbps - 48 Mbps - 36 Mbps - 24 Mbps - 18 Mbps - 12 Mbps - 11 Mbps - 9 Mbps - 6 Mbps

Operating Environment

operating temperature	0 °C to 40 °C (32 °F to 104 °F)
storage temperature	-20 °C to 65 °C (-4 °F to 149 °F)
humidity	10% minimum to 95% maximum (non-condensing)

Dimensions

length	160 mm (6.3 inches)
width	120 mm (4.72 inches)
height	59 mm (2.32 inches)
