D-Link GO-RT-N300 User Manual

27D-Link GO-RT-N300 User Manual
Section 3 - Conguration
Wi-Fi Protected (WPS) Setup
Wi-Fi Protected Setup (WPS) System is a simplified method for securing your wireless network during the “Initial setup” as well
as the “Add New Device” processes. The Wi-Fi Alliance (WFA) has certified it across different products as well as manufacturers.
The process is just as easy, as pressing a button for the Push-Button Method or correctly entering the 8-digit code for the Pin-
Code Method. The time reduction in setup and ease of use are quite beneficial, while the highest wireless security setting of
WPA2 is automatically used.
If you wish to use the Push-Button Connection (PBC) method, simply press
the WPS button on the side of the router. The power LED will begin to flash.
Within 120 seconds, press the WPS button on the device that you wish to
connect. The power LED will turn solid green if the connection is successful.
To connect using the PIN method, click Next to begin the WPS setup process.
Enter the PIN for the wireless NIC and click Start PIN. If successful, you will
then be taken to another screen and a message will tell you to run WPS in the
client device within 2 minutes.

D-Link GO-RT-N300 Specifications

Wireless Signal Rates

IEEE 802.11n 20MHz channel	150 Mbps (max)
IEEE 802.11n 40MHz channel	300 Mbps (max)
IEEE 802.11g rates	54 Mbps - 48 Mbps - 36 Mbps - 24 Mbps - 18 Mbps - 12 Mbps - 11 Mbps - 9 Mbps - 6 Mbps

Operating Environment

operating temperature	0 °C to 40 °C (32 °F to 104 °F)
storage temperature	-20 °C to 65 °C (-4 °F to 149 °F)
humidity	10% minimum to 95% maximum (non-condensing)

Dimensions

length	160 mm (6.3 inches)
width	120 mm (4.72 inches)
height	59 mm (2.32 inches)
