15.2. H2D desk cloud Registration
If you do not already have a DAB account for H2D desk cloud, please register by clicking on the appropriate button. A valid e-mail
address is required and you will receive the activation link to be confirmed.
Enter all mandatory data marked with an asterisk. Give consent to the privacy policy and fill in the required data.
Registration to the H2D desk cloud is free of charge and allows you to receive useful information for the use of DAB products.
15.3. Product Configuration
The product can be configured and monitored through a special app on the main stores. If you have any doubts, access the
internetofpumps.com website to be guided through the operation.
The app guides the installer step-by-step through the first configuration and installation of the product. The app also allows you to update
your product and enjoy DAB digital services. Refer to the H2D APP itself to complete the operation.
16. SPECIFIC CONFIGURATIONS
16.1. Vertical Configuration
Remove the 4 support feet from the bottom tray of the packaging and screw them fully into their brass seats. Put the system in place,
taking into account the dimensions:
• The distance of at least 10 mm between Face E of the system and any wall is obligatory to ensure ventilation through the grids provided.
• The distance of at least 270 mm between Face B of the system and an obstruction is recommended so as to be able to carry out
maintenance on the non-return valve without disconnecting the system.
• The distance of at least 200 mm between Face A of the system and an obstruction is recommended so as to be able to remove
the door and gain access to the technical compartment.
If the surface is not flat, unscrew the foot that is not touching and adjust its height until it contacts the surface so as to ensure the stability
of the system. The system must in fact be placed in a safe and stable position, ensuring that its axis is vertical: it must not be in an
inclined position.
16.1.1. Installation “above head”
the vertical installation of the system is of the “over head” type, it is recommended to fit a non-
return valve in the suction section
of the system; this is to allow the operation of loading the system.
If the installation is of the “over head” type, install the suction pipe from the water source to the pump in such a way as to avoid
the formation of goosenecks or siphons. Do not place the suction pipe above the pump level (to avoid the formation of air bub
in the suction pipe). The suction pipe must draw at its entrance at a depth of at least 30cm below the water level and must b
e
watertight along its whole length, as far as the entrance to the electropump.
access the technical compartment and, with the aid of the accessory tool or with a screwdriver, remove the filling cap. Fill the system
with clean water through the loading door, taking care to let the air out. If the non-return valve on the suction pipe has been placed close
to the system entry door, the quantity of water with which to fill the system should be 2.2 litres. It is recommended to fit the non-return
valve at the end of the suction pipe (foot valve) so as to be able to fill it quickly too during the loading operation. In this case the quantity
of water necessary for the loading operation will depend on the length of the suction pipe.
16.1.2. Installation “below head”
if there are no check valves between the water deposit and the system (or if they are open), it loads automatically as soon as it is allowed
to let out the trapped air. So slackening the filling cap enough to vent the trapped air allows the system to load completely. You must survey
the operation and close the loading door as soon as the water comes out (however it is recommended to fit a check valve in the section of
the suction pipe and to use it to control the loading operation with the cap open). Alternatively, in the case where the suction pipe is
intercepted by a closed valve, the loading operation may be carried out in a similar way to the one described for installation over head.
16.2. Horizontal Configuration
Remove the 4 support feet from the bottom tray of the packaging and screw them fully into their brass seats. Put the system in place,
taking into account the dimensions:
• The distance of at least 270 mm between Face B of the system and an obstruction is recommended so as to be able to carry out
maintenance on the non-return valve without disconnecting the system.
