MAINTENANCE 8-37
8
CHECKING THE FAN BELT
(1) Dust Screens
(A) Open
CLEANING THE RADIATOR


When the overheating alarm
sounds, remove straw debris
on the dust screens, radiator
nsandoilcoolernswithcom-
pressed air or a soft brush.


Open the dust screen to clean
the paddy and dust on the in-
ternal separating net and water
tank.
Regularly clean the dust screen
inside and outside; otherwise it
would be easy to cause engine
overheating.
Push the middle of the belt with
your thumb (10 kgf) and see how
much the belt deects. If the belt
deectsmorethantheacceptable
range, loosen the alternator hold-
ing bolts and move the alternator
to set up the right tension on the
belt. Then, tighten up the bolts
again.
AcceptableDeection 5 ~ 10 mm
(1) Fan Belt
(2) Alternator Holding Bolts
417O846A
(A) Pull
E32O807A
1. Don’t clean the radiator fins
with a hard tool such as iron
spatula or screw driver. Do-

and reduce the radiator’s

2. Keep water away from the
air cleaner. If water goes
into the air cleaner, the en-
gine may be damaged.
CAUTION
417O848A
(2) Radiator Fins
