If this happens, check the follow-
ing:
1. the coolant level or leakage
2. Fan belt tension
3. Any dry grasses or straws on
the dust cover, radiator or oil
tank.
SERVICE ALERT LAMPS
(1) Service Alert Lamps
417O406B
GRAIN ALARM LAMP (A)
It flickers and the horn sounds
when the hopper is full.
NO. 1 ALERT LAMP (D)
It flashes when the first outlet is
clogged. The horn is beeping.
NO. 2 ALERT LAMP (C)
It ashes when the second outlet
is clogged. The horn is beeping.
STRAW DISCHARGE ALARM
LAMP (AUTOMATIC STOP)
It flickers and the horn sounds
when the straw discharging chain
gets clogged with
trash.
C O O L A N T T E M P E R AT U R E
LAMP( )
If coolant overheats, the overheat
-
ing alarm will sound and the cool-
ant temperature lamp will icker.
OIL LAMP( )
This oil pressure lamp indicates
malfunctions in the lubrication sys-
tem during the engine’s running.
When the main switch is turned to
“ON,” this lamp comes on. When
the engine starts, it goes off.
CHARGE LAMP( )
This charge lamp indicates any
malfunctions in the charge system
during the engine’s running.
When the main switch is turned to
“ON,” this lamp comes on. When
the engine starts, it goes off.
