PARKING BRAKE
(1) Parking Brake Lever
(2) Parking Brake Pedal
(3) Arrester (A) Depress
Firmly depress the parking brake
pedal to engage it into the ar-
rester. Depress the pedal again to
release the pedal.
417O414A
(1) Threshing Clutch Lever
(A) Engage (B) Disengage
417O415A
THRESHING CLUTCH LEVER
This lever is to engage/disengage
the threshing unit.
Engage The threshing unit
operates.
Disengage The threshing unit
stops.
3. Diagonally tilting the lever al-
lows you to control the reaping
unit’s height and change the
moving direction of the combine
simultaneously.
When the threshing clutch
is engaged the engine can
not be started.
•
