Daedong KIOTI DK40SE - ADJUSTING CLUTCH PEDAL(R)

7 -20 DK35(CH)SE/DK40(CH)SE/DK45(C)HSE
H11O627A
Item Tightening torque
Front
wheel
Rear
wheel
Bolt
Nut
Bolt
Nut
H11O620A
(1) Clutch Pedal (2) Clutch Rod
(A) Free Play
Check wheel bolts and nuts regularly
especially when new. If they are loose,
tighten them as follows.
CHECKING WHEEL BOLT/NUT
TORQUE(Q)
To avoid personal injury:
 Never operate tractor with a
loose rim, wheel, or axle.
 Any time bolts and nuts are
loosened, retighten to specified
torque.
 Check all bolts and nuts fre-
quently and keep them tight.
!!
!!
!
CAUTION
ADJUSTING CLUTCH PEDAL
(R)
(1) Front Wheel Bolt/Nut
(2) Rear Wheel Bolt/Nut
MANUAL Type
