Daedong KIOTI DK40SE - PTO INDICATOR; 4 WD INDICATOR; BRAKE (ONE SIDE) LAMP

4 -18 DK35(CH)SE/DK40(CH)SE/DK45(C)HSE
H23O444A
PTO INDICATOR
H23O438A
Set the PTO switch to the “OFF”
position in order to start the
engine.
!!
!!
!
CAUTION
This indicator shows the PTO engage-
ment condition. When the PTO is
engaged, this indicator comes on. When
the PTO clutch is disengaged, this in-
dicator goes off.
This comes on to indicate 4WD
engagement.
H23O442A
4WD INDICATOR
BRAKE (ONE SIDE) LAMP
This lamp indicates the operating sta-
tus of the brake (one side). This comes
on when the brake lock for two brake
pedals is unlocked.
(1) Brake (One Side) Disengagement Bracket
H11O4E5A
The durability of the axle can
be deteriorated if only one
brake pedal is depressed during
the 4WD is activated.
!!
!!
!
CAUTION
