4
-45
DESCRIPTION OF OPERATING SYSTEM
4
WARNING
!!
!!
!
This cabin is not designed for
spraying chemicals and cannot
block polluted outside air from
entering.
(1) Internal Air Inlet (2) Air Inlet Lever
(A) Outside Air Inflow
(B) Inside Air Recirculation
It is possible to recirculate internal air
or draw fresh air by operating the air
conditioner.
When the lever is pushed to the “A”
side, outside air comes in and circu-
lates in the cabin. When it is pushed to
the “B” side, the vents are opened and
inside air circulates in the cabin.
It is not possible to block outside air
from coming in, even in the recircula-
tion mode.
In the fresh air mode, air circulating in
the cabin is 100% fresh air.
H23O491A
AIR RECIRCULATION AND
FRESH AIR MODE
