4
-32
DK35(CH)SE/DK40(CH)SE/DK45(C)HSE
To change the seatback angle, raise the
lever(1) on the left of the seat. Then,
adjust the seatback angle with the le-
ver pulled. Release the lever after
adjustment. Make sure that the lever is
returned and the seat is firmly fixed af-
ter adjustment.
SEATBACK RECLINING
(1) Seatback Adjustment Lever
H11O469A
(1) Seat adjustment lever
To adjust the seat position, pull the le-
ver(1) to left under the front of the seat,
slide the seat to the desired position,
and then release the lever.
Make sure that the seat is firmly fixed
by moving it gently after adjustment.
H11O468A
SEAT ADJUSTMENT
SEAT SLIDING
!!
!!
!
CAUTION
Do not put a hand between the
seat and the slides when adjust-
ing the seat position. You can
get injured unexpectedly.
The differential lock is to secure the dif-
ferential system and keep the wheel
rotation on both sides the same in or-
der to enhance the traction of the axle.
Depressing the pedal engages the dif-
ferential lock while releasing the pedal
disengages the differential lock.
Use this system under the following
conditions:
1. When any wheel slips and the trac-
tor does not move in the field
2. When it is hard to escape a paddy
field
To Next Page
