DK35(CH)SE/DK40(CH)SE/DK45(C)HSE
H11O498AH11O496A H11O497A
TEMPERATURE CONTROL SWITCH
The desired temperature can be set by
adjusting this dial. Warm air flows out
by turning it clockwise (red), and cool
air flows out by turning it counterclock-
wise (blue).
The temperature control dial only con-
trols the amount of air flowing through
the heater and air conditioner.
Therefore, unnecessary load can be
applied to the air conditioner if this dial
is set to the high temperature with the
A/C in operation.
Air flows out from four front vents to-
ward the driver when turning the vent
mode dial to the ( ) position.
Air flows out from four front and four left
and right vents when turning the vent
mode dial to the Bi-level ( ) position.
BI-LEVEL DEFROST
