2. Lubrication
Service Information
General Safety
WARNING
The exhaust gas contains poisonous substance. Do not keep engine idling in a closed or poorly ventilated
place for a long period of time.
Used engine oil may cause skin cancer if repeatedly left in contact with the skin for prolonged periods. It is
desirable not to handle used oil frequently; however, wash your hands thoroughly with soap and water
immediately after handling the used oil.
The oil pump can be serviced without removing the engine from the frame.
Engine Oil
API service classification: SE, SF, SH grade
Oil
Viscosity: SAE10W-30
Recommendation
(Use appropriate type of oil with viscosity
satisfying the atmospheric temperature
In your riding area based on the table shown
on the right side.)
1.1
(After disassembly)
Oil capacity
0.75
(After Oil change)
0.8
(After Oil filter change)
0.9
(After Oil change with Oil in the Oil hose removed)
20·20W
10W
30
40
20W 50
20W 40
10W 40
10W - 30
10 0 10 20 30 40℃
Pump body clearance 0.080.17(0.003-0.007) 0.23(0.009)
Rotor tip clearance 0.030.13(0.001-0.005) 0.18(0.007)
Pump side clearance 0.040.09(0.002-0.004) 0.12(0.005)
Oil filter screen cap 1.5kgm, (15Nm, 11ftIb)
Oil filter cover bolt 1.1kgm, (11Nm, 8ftIb)
Oil pump mounting bolt 1.1kgm, (11Nm, 8ftIb)
Item Standard value Tolerance
Oil Pump
Torque Values
Unit: mm(in)
2
Service information 2-1
Troubleshooting 2-2
Engine Oil Level Check 2-3
Engine Oil Change 2-3
Oil Filter Element Change 2-4
Oil Pump 2-4
Radiator 2-7
Lubrication Points 2-9
